VEGA Series – High-End LED Sports Floodlight for Professional Stadium Lighting

Product Overview

The VEGA Series High-End LED Sports Floodlight is developed specifically for professional sports facilities, where lighting performance, environmental compliance and long-term reliability are critical.

After years of in-depth research into sports lighting challenges, VEGA was engineered to overcome common industry problems such as poor optical control, excessive glare, light pollution and heavy fixture weight. By combining advanced optical technology with a compact and lightweight modular structure, VEGA provides a reliable and future-proof lighting solution for modern stadiums and large outdoor sports venues.

Reliability Built for Professional Sports Lighting

Professional sports lighting requires long-term stability under demanding conditions. VEGA is designed with a robust mechanical structure and premium components to ensure consistent performance throughout its service life.

• High-quality LED chips from OSRAM / CREE / Lumileds

• Professional Inventronics LED drivers with high power factor

• Stable operation from -40°C to +55°C

• Rated lifespan exceeding 100,000 hours (L70)

This makes VEGA suitable for stadiums that operate frequently and cannot afford lighting failure during events or competitions.

Unique Design with Lightweight Advantage

VEGA features a distinctive and compact luminaire design, clearly differentiating it from conventional stadium floodlights.

• Modular configuration with 2 or 3 LED modules

• Maximum power up to 1800W using only 3 modules

• 40% lighter than traditional stadium fixtures

• 1200W luminaire weighs only 19kg (without driver)

The lightweight structure allows easy retrofit on existing poles, reduces wind load, lowers transportation cost and improves installation safety.

Ultra-Low Light Pollution & Environmental Compliance

Light pollution is becoming a strict regulatory issue, especially in Europe. VEGA is engineered to meet these requirements through precise optical control.

• ULOR up to 0% with asymmetric optics

• ULOR <1.5% with symmetric narrow beam optics

• Optional 0° tilt installation to reduce upward light

• Minimized spill light and glare to surrounding areas

This design helps stadium owners comply with local lighting regulations while minimizing complaints from nearby residential areas.

Patented Precision Optical System

VEGA adopts patented precision optical lenses made from UV- and oxidation-resistant imported materials.

Available professional beam angles include:

• NB (Narrow Beam)

• MB (Medium Beam)

• AS-1 (Asymmetric)

• AS-LR (Long-Range Asymmetric)

These optics allow accurate light distribution for different field sizes, pole heights and layouts, ensuring high uniformity and minimal wasted light across the playing area.

Broadcast-Ready Lighting for 4K & HD Events

VEGA is designed to support modern sports broadcasting requirements.

• Flicker-free driver system

• High CRI LED options up to Ra 92

• TLCI >95, GR <35

• Suitable for HD, 4K and super slow-motion cameras

This makes VEGA ideal for televised sports events, professional competitions and stadiums with broadcast obligations.

Advanced Thermal Management System

Efficient heat dissipation is critical for high-power sports lighting. VEGA features a 4D air convection heatsink design with a large heat radiation surface.

• Ultra-low windage profile (low EPA)

• Balanced pressure respirator to protect LEDs

• Stable thermal performance under continuous operation

This ensures long LED lifespan and consistent light output even in harsh outdoor environments.

Easy Installation & Accurate Aiming

VEGA is designed to simplify installation and reduce on-site adjustment time.

• Adjustable mounting angle +105° / –105°

• Integrated laser aiming device for precise daytime focusing

• No need to rotate the luminaire on the crossbar in most installations

• Stable fixation against wind vibration

These features help contractors meet lighting design specifications with high accuracy and efficiency.

Modular Design for Easy Maintenance

The VEGA Series uses a service-friendly modular structure.

• Only 4 invisible screws to remove each LED module

• Quick replacement of LED modules and optics

• Optional remote driver mounting (on bracket, pole, inside pole or ground)

• Reduced installation and maintenance cost by at least 30%

This design minimizes downtime and simplifies spare parts management for stadium operators.

Safety-Oriented Structural Design

Safety is a priority for high-mast lighting installations.

• High-strength bracket supporting over 10× luminaire weight

• Integrated safety rope for double protection

• Tidy internal wiring with hidden connectors

• Metal cable pipe to prevent bird damage

These features ensure long-term operational safety and reliability.

Technical Highlights

• Power range: 500W / 600W / 1000W / 1200W / 1500W / 1800W

• Luminous efficiency: 140–150 lm/W

• CCT options: 3000K / 4000K / 5000K / 5700K

• CRI options: 75 / 80 / 92

• IP rating: IP67

• IK rating: IK10

• Control options: DALI / DMX / Zigbee

• Surge protection: 10kV / 20kV optional

• Certifications: ENEC / CB / CE / RoHS / LM-79 / TM-21

Applications

• Professional football stadiums

• Tennis courts and sports complexes

• Baseball and basketball fields

• Hockey fields

• Natatoriums

• Horse racing tracks

• Golf courses

Why Choose VEGA Series

• Designed specifically for professional sports lighting

• Ultra-low light pollution and glare control

• Broadcast-ready lighting quality

• Lightweight, modular and easy to maintain

• Reliable long-term outdoor performance

VEGA Series is not just a luminaire, but a complete high-end sports lighting solution.
